Quadcept 11.1.2 Released

CAD
Release Notes
目次

Fixed Issues

PCB Designer

  • Added 3D shape preview display to the CCM Component Search dialog and the Upload dialog.
  • Part output specifications for STEP export have been partially revised. (Components with registered STEP geometry are excluded from height restrictions.)
  • Improved synchronization so that PCB silkscreen and attribute display are fully linked with the 3D view.
  • Improved an issue where the system could crash during 3D rendering.

Side Note

This version fixes issues that occurred in Quadcept 11.1.0. Please see the following release notes for the changes included in Quadcept 11.1.0.

Quadcept 11.1.0 Released
Quadcept 11.1.0 Released New Features Common Made it possible to check the CCM components used and the BOM registered in CBM directly on CPM, based on the CAD project data saved in C…
