New Features

Common

  • Made it possible to check the CCM components used and the BOM registered in CBM directly on CPM, based on the CAD project data saved in CPM.
  • When uploading components to CCM, you can now specify attribute mapping and preview attribute values.
  • Expanded the CBM upload functionality (system attribute assignment, enhanced validation, support for placement-side information).
  • When replacing or updating components, you can now display a list of identical target components and select which ones to process.
  • You can now specify the placement side (Top / Bottom) for footprints assigned to components.

Symbol and footprint attribute placement and attribute search

  • Added support for placing footprint attributes.
  • Symbol attribute placement remains available using the existing functionality.
  • Separated the display of component attributes, symbol attributes, and footprint attributes to improve clarity and usability.
  • Streamlined update and replacement operations—such as component updates and component replacements—improving overall consistency.
  • Enabled searching for symbols and footprints based on attribute information.
  • Added BOM export support for symbol attributes and footprint attributes.

Complete renewal of 3D functionality

  • Added support for importing outline data via STEP input.
  • Enabled registering STEP component models to footprints.
  • Added 3D preview functionality to the component search and component detail screens.
  • Redesigned the 3D viewer to improve usability and rendering performance.
  • Enabled highlighting of components and nets within the 3D view.
  • Added 3D visualization support for PCB data (board + STEP component models).
  • Added support for importing enclosure STEP data and aligning it with the board.
  • Added STEP export capability (component models + board data + enclosure data).
  • Added viewer support for IDF, STL, and STEP formats.

Circuit Designer

  • In schematic DRC, you can now check whether “Symbol Editing” has been performed.
  • You can now set the sheet type for schematic sheets, enabling type-based print control.
  • Added the “PinName” attribute under “Type: Pin” in the Object Window.

PCB Designer

  • Renewed the automatic silkscreen-cut feature for improved usability.
  • You can now set the mounting origin for footprints, enabling coordinate output based on the specified origin.
  • Added an option for keepout areas: “Apply only to planes,” excluding pads and traces from errors.
  • Added “Below Line” as a text position option for dimension lines.

Fixed Issues

Common

  • Added batch expand/collapse operations for nodes in the Tree View.
  • Added attribute filtering to the Attribute Selection dialog.
  • Update settings in the Component Update dialog are now retained at both the project and PCB sheet levels.
  • Improved behavior so that user environment settings are retained even when uninstalling without deleting data.
  • The main window size and position are now restored upon restart.
  • Adjusted the Print dialog size for better usability.
  • Fixed an issue where prohibited characters were not removed from component names, symbol names, and footprint names when inputting UL/Samacsys data.
  • Improved behavior and fixed issues in CCM–CAD integration.
  • Improved behavior and fixed issues in CPM–CAD integration.
  • Fixed an issue where certain project data could not be opened.
  • Fixed an issue where CCM secret attributes were displayed under specific conditions.

Circuit Designer

  • Renewed the Footprint Assignment dialog to support Top/Bottom footprint selection.
  • Added an option to toggle whether zoom level is maintained during panning.
  • Components inside Device Blocks are now included in cross-probing.
  • Fixed an issue where pin assignment inconsistencies occurred during component updates under certain conditions.

PCB Designer

  • The DRC/MRC settings dialog is now resizable for better visibility of settings.
  • Added support for DXF export when keepout areas are defined on inner layers.
  • Improved input accuracy for DXF files containing splines.
  • You can now change the order of net class settings.
  • Improved accuracy and performance of connectivity check/correction.
  • Fixed a pseudo-error issue where same-net clearance DRC was triggered for objects spanning multiple design rule regions.
  • Fixed an issue where placing a “Component” in Net Input mode unintentionally assigned a footprint height.
  • Fixed an issue where updating multiple components using the same footprint caused heights to be unified incorrectly.
  • Fixed an error that occurred when importing Gerber data containing certain macro apertures.
  • Fixed an issue where PCB data was not displayed when the panel print preview was set to monochrome.
  • Fixed a malfunction occurring during panning in Pad Stack mode.
