- Added the ability to export a BOM template.
- Added the option to rotate components on the bottom layer in the opposite direction for IDF file export.
- Fixed an issue that caused all the projects in the project tree to be expanded when clicking the Reopen Last Browsing Project menu.
- Fixed an issue where saving project data containing certain control characters would fail and some data would be missing.
- Fixed an issue that caused incorrect behavior when transferring a schematic created in a CCM-unconnected environment to a PCB in a CCM-connected environment.
- Fixed an issue where pad coordinates were not displayed in the Property window after certain operations.
- Fixed an issue that caused an error when copying & pasting the components with no reference set.
- Fixed an issue where DRC clearance violations were not detected correctly under certain conditions.
- Fixed an issue that caused incorrect net description (SNT) in ODB++ files under certain conditions.
- Fixed an issue that caused an output error when exporting ODB++/IPC2581B files if a custom pad is placed in the bottom layer.
- Fixed an issue where zero-length line data would be generated in Gerber files under certain conditions.
* This does not affect the manufacturing processes.
- Optimized coordinate descriptions in Gerber files to reduce file size.
- Fixed an issue that caused an output error when exporting Gerber files if a physical layer contains prohibited characters.
- Fixed an issue where the unit setting was not reflected to the dimension values in the preview of the Auto Create Dimensions dialog.
- Fixed an issue where the Auto Create Keep Out Area command would generate component keep out areas in the inner layers.
- Fixed an issue where the type shown in the zero suppress field was incorrect when importing Excellon format Gerber files.
- Fixed an issue where a DXF file would be imported at the different scale specified in the Scale field of the Import DXF/DWG dialog in some cases.
- Fixed an issue where the angles of components on the bottom layer would not be output correctly when importing IDF files.
- Fixed an issue where hidden objects were targeted by the fit to screen command.
- Fixed minor issues found during internal testing.
